MULTI-SECTION CAPACITOR
60/40/20 uF @ 450 vdc 100 uF @ 25 vdc fp (twist-lock) can style (1) 60 uF, (1) 40 uF, (1) 20 uF @ 450 vdc (1) 100 uf @25 vdc 1 3/8″ dia. x 3″ ht (from base) Fits:…
$50.00
View Product
Out of Stock

MULTI-SECTION CAPACITOR
40/20/20/20 uf@ 525 vdc fp (twist-lock) can style. (1) 40 uf@525 vdc (3) 20 uf@525 vdc 1 3/8″ dia. x 2 1/2″ht (from base) Fits: DYNAKIT ST-70, MK III, MK IV Note: Caution, voltages with MK III may exceed 525…
$39.95
View Product
MULTI-SECTION CAPACITOR
80/40/30/20 uf@ 525 vdc fp (twist-lock) can style. (1) 80 uf @ 525 vdc (1) 40 uf @ 525 vdc (1) 30 uf @ 525 vdc (1) 20 uf @ 525 vdc 1 3/8″ dia. x 3 9/16” (from base)…
$41.95
View Product
Out of Stock

MULTI-SECTION CAPACITOR
80/40/30/20 uf@ 550/600 volt fp (twist-lock) can style. (1) 80 uf @ 550 vdc (600 V) Surge (1) 40 uf @ 550 vdc (600 V) Surge (1) 30 uf @ 525 vdc (575 V) Surge (1) 20 uf @ 550…
$80.00
View Product
MULTI-SECTION CAPACITOR
30/20/20/20 uf@ 525 vdc fp (twist-lock) can style. (1) 30 uf@525 vdc (3) 20 uf@525 vdc 1 3/8″ dia. x 3 9/16″ht (from base) Fits: DYNAKIT ST-70, MK III, MK IV Note: Caution, voltages with MK III may exceed 525…
$39.95
View Product
Out of Stock

MULTI-SECTION CAPACITOR
20/20/20/20 uF @ 475 VDC FP (twist-lock) can style. (4) 20 uF @ 475 VDC 1 3/8″ dia. x 2″ ht. (from base) Fits PAS 2/3X preamp models.
$36.95
View Product
MULTI-SECTION CAPACITOR
30/20/20/20 uF @ 550/600 VDC FP (twist-lock) can style. (1) 30 uF @ 550 VDC (600V) Surge (3) 20 uF @ 550 VDC (600V) Surge Tolerance -10/+30%, Temp Rating 70 deg C 1 3/8″ dia. x 3 1/2″ ht. (from…
$80.00
View Product
NYLON CABLE STRAPS
Screw mounted enclosed Nylon loop style straps. Use to secure cables, cords or wires. Choice of (3) sizes: (A) 3/16″ dia. (B) 1/4″ dia. (C) 3/8″ dia. Mounting hole is 0.17″ dia. Color is Black. Note: Sold as Each.

View Product
Nylon Hole Bushing
3/8” to 5/16” diameter flanged reducing bushing. Use with 5/16” diameter bias adjust potentiometer mounting. (Sold in pairs only)
$1.00
View Product
Nylon Shoulder Washers
Improved insulated washers for the original dynaco transformer covers. Fits original 8-32 hardware. Sold in sets of (4) only. Hardware not included.
$1.00
View Product
Nylon Wire Clips
Screw mount style for maximum wire bundle of 1/2″ dia. Self closing design for easy wire install/removal. Mounting hole is 0.20″ dia. Sold in sets of (2) only.
$1.00
View Product
Out of Stock

P 782 POWER XFMR
120 vac, 50/60 hz primary, secondary 410-0-410 @ 200 ma. (1) 55 volt bias tap, (1) 6.3 volt @ 5 amp tap and (1) 5 volt @ 3 amp tap. For mounting and wiring details, refer to dimensional/electrical schematic. Exact…

View Product
Out of Stock

P-782 PT (NOS) 120 / 240 vac
Rare Dynaco P-782 NOS dual voltage 120/240 vac Power Transformer. Leads were apparently shortened and stripped for installation by the former owner but I find no indication that this unit was ever used or installed in an amplifier. Unit is…

View Product
Out of Stock

P-782 PT (NOS) 120 vac
Original P-782 (NOS) 120 vac power transformer as used on the Dynaco MK III amplifier. One XFMR cloth leads have been shortened by a previous owner but I find no indication that this was ever installed and/or wired into an…

View Product
Out of Stock

P-782-S POWER XFMR
240 vac, 50/60 hz primary, secondary 410-0-410 @ 200 ma. (1) 55 volt bias tap, (1) 6.3 volt @ 5 amp tap and (1) 5 volt @ 3 amp tap. For mounting and wiring details, refer to dimensional/electrical schematic. Exact…

View Product
Out of Stock

PA 774 POWER XFMR
120 vac 50/60 hz primary, secondary 330-0-330 vac @ 180 ma (dc) rectified, plus (2) 6.3 volt taps @2.5a. For mounting and wiring details, refer to dimensional/electrical schematic. Exact drop-in replacement for Dynakit ST-35 and SCA-35 amplifiers. Includes FREE isolation mounting kit.…
$130.00
View Product
Out of Stock

PA-135 POWER XFMR
120 vac 60 hz primary, secondary 370-0-370 @ 160 ma, 55 volt bias tap, (1) 6.3 volt @ 4.5 amp tap and (1) 5 volt @ 3 amp tap. For mounting and wiring details, refer to dimensional/electrical schematic. Exact drop-in…

View Product
Out of Stock

PA-211-B Power Transformer
The new “Improved” PAS Power transformer. Our PA-211-B is a totally new design incorporating the latest advancements in both materials and transformer engineering. It is physically larger and exactly double the weight of the original Dynaco PA-211….but it still fits…
$100.00
View Product
Out of Stock

PA060 POWER XFMR
120 vac 50/60 hz primary, secondary 360-0-360 @ 300 ma, 55 volt bias tap, (2) 6.3 volt @ 5 amp taps and (1) 5 volt @ 4 amp tap. Slightly taller than the original due to increased lamination stack. Refer…

View Product
Out of Stock

PA521 POWER XFMR
240 vac 50/60 hz primary, secondary 360-0-360 @ 300 ma, 55 volt bias tap, (2) 6.3 volt @ 5 amp taps and (1) 5 volt @ 4 amp tap. Measurably taller than the original due to increased lamination stack. Refer…
$275.00
View Product
Out of Stock

PAS Chassis
The new Dynakit PAS Stainless Steel Chassis – Dimensionally accurate to the original Dyna PAS Series preamp chassis with a re-designed front panel to facilitate both the original and most all modern replacement tone & function controls. The base panel is…
$150.00
View Product
PAS Covers
Exact fit covers for your original or New Dynakit PAS preamplifier chassis. Durable polyurethane textured coating with a color choice of either Brown or black finish. Ventilation slots have been added to the cover which are both functional and stylistic!

View Product
PAS Filament Supply Kit
A modern drop-in replacement filament supply for your new or vintage PAS Preamplifier. Aerospace quality brown Polyimide circuit board with solder mask and silk screened component layout for simple trouble free installation. Includes all components, mounting hardware and step by…
$27.50
View Product
PAS Full Function RCA Jack Kit
Finally a full function RCA Jack kit which retains all Nine (9) pairs of the original PAS inputs/outputs. In addition, our kit includes a modern Mil Spec “Brown” Polyimide mounting board with integral grounding (no more wired jumpers) plus (9)…
$80.00
View Product
PAS Modern RCA Jack Kit
A high quality Modern RCA jack board with integral ground plane and isolated phono inputs. The board is constructed from Type III, 240 C rated Mil Spec “Brown” Polymide material. Wider spacing allows for use of modern RCA style interconnects…
$70.00
View Product
PAS PC-5 & PC-6
Finally, a set of Premium quality circuit boards for your PAS preamplifier. Brown Polyimide Aerospace board material with a modern ground plane, double sided solder mask, flow-thru plated holes and component silk screening. We retain the original Dynakit PAS circuitry…
$72.00
View Product
PAS Rear Label
A quality vinyl label (not paper) with peel & stick adhesive for your new or original Dynakit PAS chassis. Updated nomenclature which corresponds with our New FP-1B & FP-2N Dynakit face plates and our Modern Input/output RCA jack kit. Dimensions…
$3.50
View Product
PAS Rectifier Tube
12X4 Rectifier Tube—NOS—Vintage (1950’s-1960’s) Full Wave Rectifier. The perfect choice for your PAS preamp. Limited Supply…Various US brands…GE–RCA–Sylvania (our choice)
$25.00
View Product
PB-028-1 POWER XFMR
240 vac 50/60 hz primary, secondary 330-0-330 vac @ 180 ma (dc) rectified, plus (2) 6.3 volt taps @2.5a. For mounting and wiring details, refer to dimensional/electrical schematic. Exact drop-in replacement for Dynakit ST-35 and SCA-35 amplifiers. Includes FREE isolation mounting…
$150.00
View Product
PC-1 MKIII MF Resistors
NEW Polyimide Brown PC Board! Includes precision metal film resistors, metalized film capacitors, silver mica caps and Ceramic or Micalex tube sockets. Note: “Board Only” option does not include an assembly pictorial or parts list. Note: “Factory Built” boards are available…

View Product
PC-13 ST-35 CC Resistors
NEW Polyimide Brown PC Board! Includes carbon composition resistors, metalized film capacitors, silver mica caps, Micalex tube sockets and hardware. Priced & Sold in Pairs only. Our PC-13 boards will also fit either the original or our New SCA-35 chassis!…

View Product
PC-13 ST-35 MF Resistors
NEW Polyimide Brown PC Board! Includes precision metal film resistors, metalized film capacitors, silver mica caps, Micalex sockets and hardware. Priced & Sold in pairs only. Our PC-13 boards will fit both the original and our new ST-35 chassis. Note:…

View Product
PC-3A ST-70 MF Resistors
NEW Polyimide Brown PC Board! Includes precision metal film resistors, metalized film capacitors, silver mica caps and Ceramic or Micalex tube sockets. Original circuit for 7199 tubes. Original 7199 tube design. Note: “Board Only” option does not include an assembly…

View Product
PC-3B ST-70 MF Resistors
NEW “6GH8A” Polyimide Brown PC Board! Includes precision metal resistors, metalized film capacitors, silver mica caps and Ceramic or Micalex tube sockets. NEW 6GH8A tube design. Note: “Board Only” option does not include an assembly pictorial or parts list. Note: For 6GH8A, 6U8 or 7687…

View Product
PC-4A MKIV MF Resistors
NEW Polyimide Brown PC Board! Includes precision metal film resistors, metalized film capacitors, silver mica caps and Ceramic or Micalex tube sockets. Original circuit for the 7199 tube. Note: “Board Only” option does not include an assembly pictorial or parts list.…

View Product
PC-4B MKIV MF Resistors
New “6GH8A” Polyimide brown PC board! Includes precision metal resistors, metalized film capacitors, silver mica capacitors and Ceramic or Micalex tube sockets. New 6GH8A tube design. Note: “Board Only” option does not include an assembly pictorial or parts list. Note:…

View Product
POLYSTYRENE CAPACITORS
Foil type, ultra stable, axial leads. 630 vdc rated @5% tol. (Various brands.)

View Product
Power Cord (2) WIRE
SPT-2 flat style PVC jacketed power cord (18/2) x 6 foot length. Two prong polarized plug (Nema 1-15). Includes snap-in strain relief fitting & rubber grommet for original style chassis connection. Fits both the original and New Dynakit PAS/SCA chassis.…
$9.25
View Product
POWER CORD (C-8) STYLE
SPT-2 flat style PVC jacketed power cord (18/2) x 5 foot length. Two prong plug (Nema 1-15P) with C-8 style quick disconnect plug + chassis mounted inlet connector. This cord set will not fit the original Dynaco PAS or SCA-35…
$12.50
View Product
Power Cord + inline Switch (120 vac)
Standard 18/3 SVT, 120 vac. (0.250″ dia. x 6′ 0″ lt.) Includes inline Heavy Duty on/off switch rated 6A/125 vac, rubber grommet, cable strap and hardware. UL listed. “Nice upgrade for ST-35”.
$29.50
